65 Inch Horizontal Touch Screen Kiosk Wifi Information Query
Machine
Product Specifications:
| Specifications |
| Model No. | TQ65 |
| Panel size | 65“ TFT-LCD |
| Maximum resolution | 1366x768 |
| Display color | 16.7M |
| Pixel Pitch(mm) | 0.511(H)×0.511(V) |
| Brightness (nits) | 500cd/m2 |
| Contrast | 1500:1 |
| Visual angle | 178°/178° |
| Response time | 8ms |
| Horizontal frequency | 50-70KHZ |
| Vertical frequency | 56-75KHZ |
| Life(hrs) | >60,000(hrs) |
| Touch Panel |
| Specification | Infrared touch screen |
Positioning
accuracy | ±2mms |
| Transmittance | ≥92% |
| Hardness | 7H |
| Click manner | double point, multipoint(optional) |
| Response time | <=10ms |
| Output Resolution | 4096X4096 |
| Life time | Single point of more than 60 million |
| Input and output |
| Composite video input | 3(BNC×3) |
| YUV Input | 1 (BNC×3) |
| S-video | 1(BNC X2) |
| D-15 pin RGB input | 1 |
| HD | 1 |
| Composite video output | 2(BNC×2) |
| L/R Audio input | 1 (RCAx2) |
| L/R Audio output | 1 (RCAx2) |
| USB2.0/Serial/SP2 input | 2(for touch screen use) |
| Video |
| Color system | PAL/NTSC/SECAM |
| Compatible HD input/DVI | 480P,576P,720P,1080I,1080P |
| 3D Comb filter | Yes |
| Video reduction noise | Yes |
| OSD display( screen menu display) |
| Menu language | Chinese/English( multiple language option required) |
| Computer |
| Main chipset | Intel G41+ICH7 |
| Main board | ONDA G41 |
| System bus frequency | 800/1066/1333 MHz |
| Graphics card | Integrated IntelGMX 4500 |
| Audio card | Integrated AC97 |
| Network card | Integrated 10/100/1000M adaptive |
| Memory | 2G DDRIII (max 4G) |
| Hard Disk | 320G SATA |
| Operation system | Windows 7 |
| Power |
| Power supply | AC100V~240V,50/60Hz |
| Maximum power consumption | <=55W |
| Standby power consumption | <=1W |
| Temperature |
| Working temperature | 0°C~50°C |
| Storage temperature | -10°C~60°C |
| Working humidity | 20%~80% |
| Storage humidity | 5%~95% |
| Appearance |
| Panel color/appearance | White, black, customized |
| Panel material | SPCC/Aluminum/Customized |
| Installation | Wall-mounted(default), desktop |
| Certificate | CE/FCC/3C/RoHS |
| Accessories | Manual,remote control, data line1.5 M, power line 1.8 M |
About TSINGHILL
Guangdong TSINGHILL Technology Co., Ltd, located in Building 8,
Zhongji Intelligent Valley, Foshan City, Guangdong, China, is
Specialized in doing 32inch ~ 110 inch all in one touch screen
smart board for education, conference, home use and so on. In the
year 2016, We set up our own brand “TSINGHILL”, which is selling
good in domestic China market. Now it's the top 1 brand selling on
line, covered 60% market selling quantity.
Dedicated to strict quality control and thoughtful customer
service, our experienced staff members are always available to
discuss your requirements and ensure full customer satisfaction. In
addition, we have obtained FCC, ISO 9001, ROSH, CE certificates.
Selling well in all cities and provinces around China, our products
are also exported to clients in such countries and regions as
Europe, America, Southeast Asia and Africa.
We also welcome OEM and ODM orders. Whether selecting a current
product from our catalog or seeking engineering assistance for your
application, you can feel free to talk to our customer service
center about your sourcing requirements. We are also keeping
searching and developing our new products to satisfy new demands
from customers.
High quality, reasonable price and good services always are our
promise to all of our customers. We will try our best to do better.
Product Details:
Product Features:
Intelligent Split Screen Multi-purpose
Video and pictures can be played simultaneously, logo, whether,
time, date and scrolling subtitles can also appear at the same
time. Massive split screen modules can be applied, or you can
design your own split screen modules to meet the needs of
multi-task.
Built-in WIFI Receiver
Built-in wireless WIFI module, enjoy network experience download
function, make data interaction more convenient, multi-person
interaction with the same screen competitive game entertainment.
Cloud Intelligent Information Release
The use of cloud intelligent information release system, remote
management advertising machine. Multi-terminal login, cloud
management, real-time monitoring, synchronous update and release ,
materials.
Energy Conservation And Environmental Protection
Super long standby, support 7*24 hours uninterrupted work,
integration without physical loss, overall heat dissipation to play
to the best, energy saving and low power consumption.
4K Ultra HD Screen
The use of bright color full HD screen, restore the natural
delicate image.
Ergonomic Design
Horizontal design, in line with human reading and writing posture,
easy to touch view. Adopt energy saving and environmental
protection material
Dual System Selection
Android/Windows dual system free to choose, compatible with a
variety of query software, support massive download.
Strong Performance
Select Core Processors
Faster response, easier to run more tasks, give you a flying smooth
experience.
