Customized 65 Inch Horizontal Touch Information Inquiry Machine For
Hotel
Product Specifications:
| Specifications |
| Model No. | TQ65 |
| Panel size | 65“ TFT-LCD |
| Maximum resolution | 1366x768 |
| Display color | 16.7M |
| Pixel Pitch(mm) | 0.511(H)×0.511(V) |
| Brightness (nits) | 500cd/m2 |
| Contrast | 1500:1 |
| Visual angle | 178°/178° |
| Response time | 8ms |
| Horizontal frequency | 50-70KHZ |
| Vertical frequency | 56-75KHZ |
| Life(hrs) | >60,000(hrs) |
| Touch Panel |
| Specification | Infrared touch screen |
Positioning
accuracy | ±2mms |
| Transmittance | ≥92% |
| Hardness | 7H |
| Click manner | double point, multipoint(optional) |
| Response time | <=10ms |
| Output Resolution | 4096X4096 |
| Life time | Single point of more than 60 million |
| Input and output |
| Composite video input | 3(BNC×3) |
| YUV Input | 1 (BNC×3) |
| S-video | 1(BNC X2) |
| D-15 pin RGB input | 1 |
| HD | 1 |
| Composite video output | 2(BNC×2) |
| L/R Audio input | 1 (RCAx2) |
| L/R Audio output | 1 (RCAx2) |
| USB2.0/Serial/SP2 input | 2(for touch screen use) |
| Video |
| Color system | PAL/NTSC/SECAM |
| Compatible HD input/DVI | 480P,576P,720P,1080I,1080P |
| 3D Comb filter | Yes |
| Video reduction noise | Yes |
| OSD display( screen menu display) |
| Menu language | Chinese/English( multiple language option required) |
| Computer |
| Main chipset | Intel G41+ICH7 |
| Main board | ONDA G41 |
| System bus frequency | 800/1066/1333 MHz |
| Graphics card | Integrated IntelGMX 4500 |
| Audio card | Integrated AC97 |
| Network card | Integrated 10/100/1000M adaptive |
| Memory | 2G DDRIII (max 4G) |
| Hard Disk | 320G SATA |
| Operation system | Windows 7 |
| Power |
| Power supply | AC100V~240V,50/60Hz |
| Maximum power consumption | <=55W |
| Standby power consumption | <=1W |
| Temperature |
| Working temperature | 0°C~50°C |
| Storage temperature | -10°C~60°C |
| Working humidity | 20%~80% |
| Storage humidity | 5%~95% |
| Appearance |
| Panel color/appearance | White, black, customized |
| Panel material | SPCC/Aluminum/Customized |
| Installation | Wall-mounted(default), desktop |
| Certificate | CE/FCC/3C/RoHS |
| Accessories | Manual,remote control, data line1.5 M, power line 1.8 M |
About TSINGHILL
Guangdong TSINGHILL Technology Co., Ltd, located in Building 8,
Zhongji Intelligent Valley, Foshan City, Guangdong, China, is
Specialized in doing 32inch ~ 110 inch all in one touch screen
smart board for education, conference, home use and so on. In the
year 2016, We set up our own brand “TSINGHILL”, which is selling
good in domestic China market. Now it's the top 1 brand selling on
line, covered 60% market selling quantity.
Dedicated to strict quality control and thoughtful customer
service, our experienced staff members are always available to
discuss your requirements and ensure full customer satisfaction. In
addition, we have obtained FCC, ISO 9001, ROSH, CE certificates.
Selling well in all cities and provinces around China, our products
are also exported to clients in such countries and regions as
Europe, America, Southeast Asia and Africa.
We also welcome OEM and ODM orders. Whether selecting a current
product from our catalog or seeking engineering assistance for your
application, you can feel free to talk to our customer service
center about your sourcing requirements. We are also keeping
searching and developing our new products to satisfy new demands
from customers.
High quality, reasonable price and good services always are our
promise to all of our customers. We will try our best to do better.
Product Details:
FAQ:
Q: What kind of inspection you can provide?
A: TSINGHILL has multiple tests from material purchasing to
finished products by different departments, like QA, QC, sales
representative, to guarantee all signage players are in perfect
condition before shipment. We also accept the inspection by the
third party you appointed.
Q: Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed
samples are acceptable.
Q: What about the lead time?
A: Sample needs 3-5 days, mass production time needs 2-4 weeks.
Q: Do you have any MOQ limit for order?
A: 1pc for sample checking is available.
Q: How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes
several days to arrive. Airline and sea shipping are also optional.
Q: How to proceed an orders?
A: Firstly, let us know your requirements or application.
Secondly, we quote according to your requirements or our
suggestions.
Thirdly, customer confirms the samples and places deposit for
formal order.
Fourthly, We arrange the production.
Q: Is it OK to put my logo on the product?
A: Yes. Please inform us formally when you place the order and
confirm the design firstly based on our sample.
Q: Do you offer guarantee for the products?
A: Yes, we offer 12 months warranty to our products.
